| Herkunftsort: | Jiangsu.China |
|---|---|
| Markenname: | Dagyee |
| Zertifizierung: | ISO9001 |
| Modellnummer: | DT6660 |
| Min Bestellmenge: | 1pcs |
| Preis: | negotiable |
| Verpackung Informationen: | Holzkiste, Standardbehälter, Kunden kann Anforderungen spezifizieren |
| Lieferzeit: | 20-30 Arbeitstage |
| Zahlungsbedingungen: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Versorgungsmaterial-Fähigkeit: | 30set |
| Bedingung: | Neu | Produktname: | Polymervorbereitung, die System dosiert |
|---|---|---|---|
| Material: | 304 316 | Kapazität: | 6500 |
| Wassereinlassfluß: | 4.2-20 | Gewicht: | 1200 |
| Anwendung: | Chemikalienlager | Garantie: | 1-jährig |
| Hervorheben: | SUS316 polymer preparation unit,SUS304 polymer preparation unit,1000l polymer preparation unit |
||
Dagyee DT6660 Automatic Three Chamber Intelligent Dosing Control Systems Polymer Preparation
Integrated dosing device for automatic batching,dissolution and integration into one ,and Fully automatic operation.
The quantitative dosing device is accurate in measurement and driven by continuously variable transmission,it is convenient to adjust the feeding amount.The concentration range of preparation agent is large.
With liquid level detection, flow control, auxiliary vibration feeding and other functions, high degree of automation.4.Tank material: stainless steel SS304 or SS316L, polypropylene PP, FRP, etc
Specification
Extraction rate up to 10,000 l / h
Liquid polymer concentration: 0.05 – 1%
Powder polymer concentration: 0.05-0.5%
| AUTOMATIC POLYMER DOSING SYSTEM EQUIPMENT SPECIFICATIONS | |||||||||||||
| PT Model |
Capacities (L/h) |
Tank volume (L) | Influent volume | Aging Time | Piping Connections | Physical Dimensions(mm) | Weight (Kg) |
Power | |||||
| (m3/h) | (h) | Inlet | Dosing | Vent | Overflow | L/L1 | W/W1 | H | (KW) | ||||
| PT300 | 300 | 350 | 0.12-0.6 | 1.0-1.5 | DN20 | DN20 | DN20 | DN32 | 940/860 | 470/520 | 1450 | 250 | 0.54 |
| PT500 | 500 | 750 | 0.3-1.5 | 1.0-1.5 | DN25 | DN25 | DN25 | DN32 | 1370/1290 | 680/730 | 1450 | 350 | 0.92 |
| PT1000 | 1000 | 1580 | 0.6-3 | 1.0-1.5 | DN25 | DN25 | DN25 | DN40 | 1800/1720 | 900/950 | 1620 | 480 | 1.3 |
| PT1500 | 1500 | 2200 | 0.8-4 | 1.0-1.5 | DN32 | DN32 | DN25 | DN40 | 2130/2050 | 1070/1120 | 1620 | 560 | 1.7 |
| PT2500 | 2500 | 4050 | 1.6-8 | 1.0-1.5 | DN40 | DN40 | DN40 | DN50 | 2450/2370 | 1220/1270 | 2000 | 790 | 2.4 |
| PT4000 | 4000 | 6170 | 2.4-12 | 1.0-1.5 | DN40 | DN40 | DN40 | DN65 | 2780/2700 | 1390/1440 | 2250 | 1050 | 3.2 |
Complete PAM Batching Metering Systems
The polymer preparation unit automatically prepares polymer solutions used as coagulants, and these solutions can be used for suspended particles in water treatment processes from swimming pool maintenance to wastewater treatment, as well as oil recovery, color removal, papermaking and beneficiation.
The Dagyee series contains 6 models and can provide polymer solutions up to 4000 l / h. This series is also equipped with various electrical control panels, mixers, optional diaphragm pumps and tank sizes to provide the best solution for every application. Its design also means that Dagyee offers a flexible and compact footprint solution to fit in tight spaces.
The Feature Of Dissolver Dosing Device
The Application Of Dissolver Dosing Device
The Service Of Company
No matter which processes and applications are planned Dagyee has a solution in the cleaning and hygiene of kitchens and laundries and surfaces of all types in applications like Offices and Restaurants, Hospitals and Hotels, Retailers andSchools, Car Washes and Swimming Pools, Cooling Towers, Energy, Food & Beverage, Water & Gas Utilities Potable and Waste Water Treatment .
